LONGFRAME SWITCHBOARD SWITCHES
JACK PANELS
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
LONGFRAME SWITCHBOARD SWITCHES
SERIES 11000 and 11200
Premium quality, long frame switches, designed especially for
jack panel mounted switching. Standard actuations are
push-lock/pull-release, 2-position turn button and 3 position turn
button. Many contact forms available. Mounts in Switchcraft
Jack Panels Series 1200, 1400, 2400, 2600, 2800, modular JP ?
231
jack panels, and other standard telephone jack panels. Part
numbers in table indicate “A” frame. For same switch with “C”
frame, add prefix “C” to part number. Many circuit forms not
shown in tables are available on special order. Long leaf springs
have no forms at point of flexing, which insures long life. Welded
crossbar palladium contacts rated at 2A 200W maximum are
W11012L
Part Numbers
Locking Momentary
11206L
Circuit
standard. Fine silver (for higher currents) or gold alloy (dry circuit
to 1A) contacts are available on special order. Contact Switchcraft.
PUSHBUTTONS - SERIES 11000
? 11001L ? 11001 1-A
SPECIFICATIONS
Frame, Screws and Twin Nut: Steel, plated.
Springs, Pressure Plate and Terminals: Copper alloy.
Solder lugs are tin-dipped.
Contacts: Welded crossbar palladium are standard. Fine sil-
ver or gold alloy are available on special order.
Insulation: Rigid plastic. Extruded plastic tubing through
stack.
Knob: Molded black plastic. Turn-key type faced with white
arrow.
Bushing: Copper alloy, nickel-plated.
? 11002L
11003L
? W11003L
? 11003DL
? 11004L
? 11005L
11006L
? W11006L
? 11006DL
? 11008L
? 11009L
? 11012L
? W11012L
? 11002
11003
? W11003
? 11003D
? 11004
? 11005
11006
? W11006
? 11006D
? 11008
? 11009
11012
? W11012
1-B
1-C
1-D
2-A
2-B
2-C
2-D
4-A
3-C
4-C
ORDERING
TURN BUTTONS - SERIES 11200
1. Order by part number from table.
2. For special order items, contact Switchcraft.
? 11201L
? 11202L
11203L
? W11203L
? 11203DL
? 11204L
? 11205L
11206L
? W11206L
? 11206DL
? 11208L
? 11209L
? 11212L
? W11212L
? 11201
? 11202
11203
? W11203
? 11203D
? 11204
? 11205
11206
? W11206
? 11206D
? 11208
? 11209
11212
? W11212
1-A
1-B
1-C
1-D
2-A
2-B
2-C
2-D
4-A
3-C
4-C
? Special order only; contact Switchcraft.
Mounting Screws: #6-32, P10725 , can be ordered separately.
Contact Switchcraft. (Screws not supplied with switches.)
“T-Switch” Switches
A
B
C
D
E
F
Basic Schematic Circuits
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
